PVC anticorrosive tape is "All Weather" pipe protection tape. The tape is composed of PVC plastic backing and high adhesion synthetic rubber adhesive. The adhesive layer is composed of butyl rubber(BR) or butyl rubber base modified bitumen compound(BC). The PVC plastic backing has excellent electrical insulation and chemical resistance. The synthetic adhesive has excellent anti-aging, seal ability effect. So it is always used for corrosion protection for metal piping systems above and below ground.
PVC anticorrosive tape is easy to apply with no special tools or equipment. Being highly flexible, it is suitable for work in low temperature and for work on joint part or flexural area. It provides positive protection against abrasion and corrosive action for steel pipe, fittings or electrical conduit systems.
Features:
Offers superior durability and corrosion resistance.
Consists of flexible film and thick adhesive. Adheres well to joints and curved part. Provides superior sealing and cushioning. For anticorrosion and protection of various types of pipelines.
Structure:
Standard Ordering options:
Test Data sheet
|
Physical
Properties
|
Test
Method
|
T540BR-16
|
T550BR-20
|
T5150BC-60
|
T5165BC-65
|
|
Metric
|
English
|
Metric
|
English
|
Metric
|
English
|
Metric
|
English
|
|
Total
Thickness
|
ASTM D
1000
|
0.41mm
|
16mils
|
0.51mm
|
20mils
|
1.50mm
|
59mils
|
1.65mm
|
65mils
|
|
Backing
Thickness
|
ASTM D
1000
|
0.28mm
|
11mils
|
0.31mm
|
12mils
|
0.50mm
|
20mils
|
0.75mm
|
30mils
|
|
Adhesive
Thickness
|
ASTM D
1000
|
0.13mm
|
5mils
|
0.20mm
|
8mils
|
1.00mm
|
39mils
|
0.90mm
|
35mils
|
|
Elongation
|
ASTM D
1000
|
225%
|
225%
|
250%
|
250%
|
270%
|
270%
|
300%
|
300%
|
|
Tensile
Strength
|
ASTM D
1000
|
98 N/25mm
|
22
lbs/in
|
148
N/25mm
|
33.3
lbs/in
|
372 N/25mm
|
83.6
lbs/in
|
392 N/25mm
|
88.1
lbs/in
|
|
Peel strength to Primed Pipe
|
ASTM D
1000
|
59
N/25mm
|
212.4
oz/in
|
61 N/25mm
|
219.6
oz/in
|
88 N/25mm
|
316.8 oz/in
|
88 N/25mm
|
316.8
oz/in
|
|
Adhension to
Self
|
ASTM D
1000
|
13 N/25mm
|
46.8
oz/in
|
13
N/25mm
|
46.8
oz/in
|
78
N/25mm
|
280.8
oz/in
|
78
N/25mm
|
280.8
oz/in
|
|
Impact Resistance
|
ASTMG 14
|
11 Nm
|
97.36
in-lbs
|
11 Nm
|
97.36
in-lbs
|
15 Nm
|
132.76 in-lbs
|
15 Nm
|
132.76 in-lbs
|
|
Tear Strength
|
ASTM D
1004
|
40 N
|
8.99 lbs
|
43 N
|
9.67 lbs
|
50 N
|
11.24 lbs
|
51 N
|
11.47 lbs
|
|
Dielectric
Strength
|
ASTM D149
|
30 KV
|
30 KV
|
35 KV
|
35 KV
|
38 KV
|
38 KV
|
40 KV
|
40 KV
|
|
Insulation
Resistance
|
ASTM D
257
|
108
Mohm
|
10E 8
Mohm
|
1010
Mohm
|
10E10
Mohm
|
1012
Mohm
|
10E12
Mohm
|
1012
Mohm
|
10E12
Mohm
|
|
Water Vapor
Transmission
Rate (24h)
|
ASTM E96
|
0.1
g/m2·24h
|
0.0065
g/100sqin
/24h
|
0.1 g/m2·24h
|
0.0065g
/100sqin
/24h
|
0.2
g/m2·24h
|
0.013
g/100sqin
/24h
|
0.2
g/m2·24h
|
0.013
g/100sq
in/24h
|
|
Water
Absorption
|
ASTM D
570
|
0.08%
|
0.08%
|
0.08%
|
0.08%
|
0.10%
|
0.10%
|
0.10%
|
0.10%
|
|
Application
Temperature
|
-34 ºC to +85 ºC ( -29 ºF to 185 ºF )
|
|
Operating
Temperature
|
+85 ºC ( 185 ºF )
|
|
Color
|
Black, White, Yellow, Blue
|
|
Tape width
in inches
|
25mm(1"),50mm(2"),75mm(3"),101mm(4"),152mm(6"),228mm(9"),305mm(12"),457mm(18"),
610mm(24"),750mm(29.5")
|
|
Tape roll
length in
feet
|
10m(33ft),15m(50ft),25m(82ft),30m(98ft),50m(164ft),61m(200ft),100m(328ft),122m(400ft),
183m(600ft),244m(800ft)
|
|
Core size
|
30mm(1.2"),38mm(1.5"), 76mm(3") core of paper or hard plastic
|
|
