Model A
| Horse power: |
1/3 |
| Batch size water: |
20 liters |
| Description: |
Light Duty |
| Gear ratio: |
Direct |
| Max. rpm: |
10,000 |
| Torque:* |
4 in-lbs |
| Air input psi: |
30 to 100 |
| Air consumption:* |
13 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
5 lbs (2.3 kg) |
|
| Price Each: |
$299.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
Model G
| Horse power: |
1/3 |
| Batch size water: |
100 liters |
| Description: |
Heavy Duty |
| Gear ratio: |
7 to 1 |
| Max. rpm: |
1,200 |
| Torque:* |
18 in-lbs |
| Air input psi: |
30 to 80 |
| Air consumption:* |
13 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
6 lbs (2.7 kg) |
|
| Price Each: |
$440.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
| |
|
|
|
|
|
|
Model A-5
| Horse power: |
1/2 |
| Batch size water: |
100 liters |
| Description: |
Medium Duty |
| Gear ratio: |
Direct |
| Max. rpm: |
7,000 |
| Torque:* |
6 in-lbs |
| Air input psi: |
30 to 100 |
| Air consumption:* |
27 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
5 lbs (2.3 kg) |
|
| Price Each: |
$404.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
Model G-5
| Horse power: |
1/2 |
| Batch size water: |
100 liters |
| Description: |
High Torque/ Heavy Duty |
| Gear ratio: |
7 to 1 |
| Max. rpm: |
1,000 |
| Torque:* |
26 in-lbs |
| Air input psi: |
30 to 80 |
| Air consumption:* |
27 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
6 lbs (2.7 kg) |
|
| Price Each: |
$577.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
| |
|
|
|
|
|
Model A-RV (reversible)
| Horse power: |
1/2 |
| Batch size water: |
100 liters |
| Description: |
Medium Duty |
| Gear ratio: |
Direct |
| Max. rpm: |
7,000 |
| Torque:* |
6 in-lbs |
| Air input psi: |
30 to 100 |
| Air consumption:* |
27 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
5 lbs (2.3 kg) |
|
| Price Each: |
$404.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
Model G-RV (reversible)
| Horse power: |
1/2 |
| Batch size water: |
100 liters |
| Description: |
High Torque/ Heavy Duty |
| Gear ratio: |
7 to 1 |
| Max. rpm: |
1,000 |
| Torque:* |
26 in-lbs |
| Air input psi: |
30 to 80 |
| Air consumption:* |
27 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
6 lbs (2.7 kg) |
|
| Price Each: |
$577.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
| |
|
|
|
|
|
Model GG
| Horse power: |
1/3 |
| Batch size water: |
20 liters |
| Description: |
Low rpm |
| Gear ratio: |
49 to 1 |
| Max. rpm: |
170 |
| Torque:* |
100 in-lbs |
| Air input psi: |
30 to 60 |
| Air consumption:* |
13 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
7 lbs (3.2 kg) |
|
| Price Each: |
$625.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
Model G-HD (steel gears)
| Horse power: |
1/3 |
| Batch size water: |
100 liters |
| Description: |
Heavy Duty |
| Gear ratio: |
7 to 1 |
| Max. rpm: |
1,200 |
| Torque:* |
18 in-lbs |
| Air input psi: |
30 to 80 |
| Air consumption:* |
13 cfm |
| Motor shaft dia.: |
3/8" |
| Weight: |
6 lbs (2.7 kg) |
|
| Price Each: |
$465.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
| |
|
|
|
|
|
|
Model 750
| Horse power: |
3/4 |
| Batch size water: |
200 liters |
| Description: |
High Torque |
| Gear ratio: |
Direct |
| Max. rpm: |
3,000 |
| Torque:* |
28 in-lbs |
| Air input psi: |
40 to 100 |
| Air consumption:* |
20 cfm |
| Motor shaft dia.: |
1/2" |
| Weight: |
8 lbs (3.7 kg) |
|
| Price Each: |
$708.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
Model 1500
| Horse power: |
1-1/2 |
| Batch size water: |
250 liters |
| Description: |
High Torque |
| Gear ratio: |
Direct |
| Max. rpm: |
3,000 |
| Torque:* |
56 in-lbs |
| Air input psi: |
40 to 100 |
| Air consumption:* |
42 cfm |
| Motor shaft dia.: |
1/2" |
| Weigh: |
10 lbs (4.6 kg) |
|
| Price Each: |
$750.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
| |
|
|
|
|
|
Model 1500-RV (reversible)
| Horse power: |
1-1/2 |
| Batch size water: |
250 liters |
| Description: |
High Torque |
| Gear ratio: |
Direct |
| Max. rpm: |
3,000 |
| Torque:* |
56 in-lbs |
| Air input psi: |
40 to 100 |
| Air consumption:* |
42 cfm |
| Motor shaft dia.: |
1/2" |
| Weigh: |
10 lbs (4.6 kg) |
|
| Price Each: |
$750.00 |
Shipping UPS ground in the United States only.
Any other shipping should contact us. |
|
|
|
|
| |
|
|
|
