Heat Shrinkable Tape (HST)
|
|
|
|
| |
|
Product profile
Heat Shrinkable Tape is a hand wrapped heat shrinkable tape designed for corrosion protection of straight pipes, fittings, bends, elbows and other irregular configurations. It has a cross linked polyethylene backing coated with butyl rubber based thermoplastic adhesive. When heated the backing layer shrinks and the adhesive flows and forms a reliable corrosion protection seal onto metal and adjacent coating surfaces.
Long-term Corrosion Protection:
After heating, formed corrosion protection seal, and strong backing provides outstanding waterproofing effect and high chemical resistance. Heat Shrinkable Tape resists impact, abrasion and ultraviolet light. Excellent resistance against cathodic disbondment, dielectric breakdown.
Physical Properties:
|
Physical Properties
|
Test Method
|
Typical Values
|
|
Adhesive
|
Thickness
|
ASTM D 1000
|
0.70 mm to 1.00mm
|
|
Softening Point
|
ASTM E 28
|
99°C(210°F)
|
|
Lap Shear
|
23℃ |
ASTM D 1002
|
2.6Mpa(377psi)
|
| 60℃ |
0.18Mpa(26psi) |
|
Backing
|
Thickness
|
ASTM D 1000
|
0.50 mm to 1.50mm
|
|
Tensile Strength
|
ASTM D 638
|
20 Mpa(2900psi)
|
|
Elongation
|
ASTM D 638
|
550%↑
|
|
Hardness
|
ASTM D 2240
|
45 Shore D
|
|
Dielectric Breakdown
|
ASTM D 149
|
30 KV
|
|
Tape
|
Thickness
|
ASTM D 1000
|
1.20 mm to 2.50mm
|
|
Impact Strength
|
ASTM G 14
|
15 N•m↑
|
|
Low-temperature Flexibility
|
ASTM D 2671-C
|
-35℃(-31℉)↑
|
|
Water Absorption
|
ASTM D 570
|
0.05%↓
|
|
Cathodic Disbondment
|
ASTM G 8
|
10mm
|
|
Peel strength
|
To Primer Steel
|
ASTM D 1000
|
100 N/cm
|
|
To PE Lining
|
85 N/cm
|
|
Max. Operation Temperature
|
65℃（149℉）
|
|
Available Roll Size(width×length)
|
50 to 500 mm ×10 to 60 m
|
Application Table (Length of Tape Required):
|
Pipe Size
|
Tape Width
|
Tape Length
|
The following formula can be used:
Length of tape=Pipe Ø x 3.14 x L/W
L=length of area to be covered.
W=1/2 of tape width(50% overlap)
|
|
DN
|
Inch
|
(mm)
|
(Inch)
|
(m)
|
(ft)
|
|
25
40
50
80
100
125
150
200
250
300
>300
|
1
1.5
2
3
4
5
6
8
10
12
>12
|
50
50
50
50
50
75
75
100
100
100
150
|
2
2
2
2
2
3
3
4
4
4
6
|
2.8
4.0
5.2
8.5
11.1
12.3
14.3
16.3
23.1
30.4
formula
|
9.2
13.1
17.1
27.9
36.4
40.4
46.9
53.5
75.8
99.7
-
|
Working drawing
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
