FF series Fire Fighting Pump

FEATURES
It is manufactured by the standards of National Fire Agency of fire protection codes It conforms to     CNS8917 B4052：For fire fighting booster centrifugal pumps     CNS8918 B4053：For fire fighting booster centrifugal pumps--prime movers.     CNS8919 B4054：For fire fighting booster centrifugal pumps--auxiliary equipments.     Pump models are approved by Chinese Fire Protection Safety Center(CFS). Every batch of pumps can only get nameplates from CFS by way of examined and tested each time. It adopts with totally enclosed fan-cooled (TEFC) "TATUNG" motors.     Conforms to CNS14400 C4482 standards. IP54. Insulation: Class B / F.     Adopts with Japan"FLOWAY" flowmeter which is approved by fire protection codes.     Adopts with exclusive modularized design for main pipeline. It has good appearance、pressure resistance、easy maintenance and repair effects.
APPLICATIONS
Indoor and outdoor hydrant systems、foam systems、sprinkler systems、boosting systems、junction systems for boosting water.
OPERATING CONDITIONS
1. Ambient temperature:  0~+50℃ 2. Liquid temperature:  +4~+80℃ 3. It is suitable for clean water or non chemical property liquid. It should not contain solid particles in the liquid. 4. Working pressure: 10~20Bar (Different water pumps withstand different pressure resistance.)
SPECIFICATION
Horsepower: 7.5HP~300HP Protection: IP54~55 Insulation: B,F R.P.M: 2P,4P Voltage: 3 phase 220/380/440/660*60HZ              3 phase  380~415V*50HZ  Discharge/suction diameter: 21/2” ~10” Head:  Max. 230 M Capacity:  18~830M³/hr.
DOWNLOAD
FF Fire-fighting Pump Brochure Download(50HZ) (Link)  FF Fire-fighting Pump Brochure Download(60HZ) (Link)  FF Fire-fighting Pump Performance Curves Download-FF-XA(50HZ) (Link)  FF Fire-fighting Pump Performance Curves Download-FF-ISO(50HZ) (Link)
